Hi there,
we cant get SNMP to work through EMP Port. On our switches which are direct accessible through default ports, we have no problem.
This is our basic snmp config
user checkmk password-prompt prompt-priv-password read-only all sha256+aes
user checkmk allow-ssh disable
aaa authentication snmp local (oder default)
snmp station 10.50.63.110 162 "checkmk" v3 enable
snmp security privacy all
routing seems to be fine
show ip interface EMP-CHAS1
Interface Name = EMP-CHAS1
SNMP Interface Index = 13604100,
IP Address = 10.50.6.20,
Subnet Mask = 255.255.255.0,
Broadcast Address = 10.50.6.255,
Device = EMP-CHAS1,
Forwarding = disabled,
Administrative State = enabled,
Operational State = up,
Maximum Transfer Unit = 1500,
sh ip router database gateway 10.50.6.1
Destination Gateway Interface Protocol Metric Tag Misc-Info
---------------------+---------------+--------------------------------+--------+-------+----------+-----------------
10.0.0.0/8 10.50.6.1 EMP STATIC 1 0
snmpinpkts are received by the switch but none goes out
sh snmp statistics
From RFC1907
snmpInPkts = 970
snmpOutPkts = 0
Systeminfo
sh system
System:
Description: Alcatel-Lucent Enterprise OS6900-X24C2 8.10.93.R03 GA, June 14, 2025.,
SSH, HTTPS works fine through the emp interface but how do we get snmp to work?
Any help is very appreciated
